R48; Mivar VAR; Milano (ID = 619708) Radio
Mivar VAR; Milano: R48 [Radio] ID = 619708 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model R48, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: BF235 BF235 BF233 BF233 BF233 BC205 BC208 AC180 AC181
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: R48 - Mivar VAR; Milano
Material Plastics (no bakelite or catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 331 x 150 x 125 mm / 13 x 5.9 x 4.9 inch
Notes

Veniva costruito anche un modello dotato di ganci per essere appeso.

Dial lamps: 2 x 6V/0,05A.

Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Price in first year of sale 28'600.00 ITL
Mentioned in Catalogo ANIE (1970-71, p. 77)

Model page created by Malte Rosenbaum. See "Data change" for further contributors.



All listed radios etc. from Mivar (VAR); Milano
Here you find 117 models, 105 with images and 67 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
