R56

R56 ; Mivar VAR; Milano (ID = 2355204) Radio

R56 ; Mivar VAR; Milano (ID = 2355205) Radio
R56 ; Mivar VAR; Milano (ID = 2275658) Radio R56 ; Mivar VAR; Milano (ID = 657027) Radio
R56 ; Mivar VAR; Milano (ID = 657030) Radio R56 ; Mivar VAR; Milano (ID = 657028) Radio
R56 ; Mivar VAR; Milano (ID = 657029) Radio R56 ; Mivar VAR; Milano (ID = 657031) Radio
R56 ; Mivar VAR; Milano (ID = 657032) Radio R56 ; Mivar VAR; Milano (ID = 2275657) Radio
R56 ; Mivar VAR; Milano (ID = 2275659) Radio R56 ; Mivar VAR; Milano (ID = 2275660) Radio
Use red slider bar for more.
R56 ; Mivar VAR; Milano (ID = 2275658) Radio
Mivar VAR; Milano: R56 [Radio] ID = 2275658 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model R56, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1974 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: BF255 BF255 BF255 BF255 BF253 BF253 BF253 TAA611 B20C200 or. B30C400
Main principle Superheterodyne (common); ZF/IF 460 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / C: 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: R56 - Mivar VAR; Milano
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 282 x 170 x 72 mm / 11.1 x 6.7 x 2.8 inch
Notes

7 transistor 1 IC

Antenna estraibile esterna per FM - antenna in ferrite interna per AM - maniglia di trasporto - consumo 3 watt.

Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)

Model page created by Fabio Masetti. See "Data change" for further contributors.
