R-41

R-41; Mivar VAR; Milano (ID = 570767) Radio
R-41; Mivar VAR; Milano (ID = 570761) Radio R-41; Mivar VAR; Milano (ID = 570758) Radio
R-41; Mivar VAR; Milano (ID = 570762) Radio R-41; Mivar VAR; Milano (ID = 570759) Radio
R-41; Mivar VAR; Milano (ID = 570760) Radio R-41; Mivar VAR; Milano (ID = 2510079) Radio
R-41; Mivar VAR; Milano (ID = 2510080) Radio
Use red slider bar for more.
R-41; Mivar VAR; Milano (ID = 570761) Radio
Mivar VAR; Milano: R-41 [Radio] ID = 570761 850x638
Select picture or schematic to display from thumbnails on the right and click for download.
For model R-41, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1971 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: BF195 or. BF235 BF195 or. BF235 BF195 or. BF233 BF195 or. BF233 BF195 or. BF233 BF159 or. BC205 BC148 or. BC208 AC188 or. AC180 AC187 or. AC181 AA119 or. 1N542 AA119 or. 1N542 AA119 or. 1N542 AA119 or. SFD106 BZY88 or. 1N963 B30C300 or. B30C400
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; 3 AF stage(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: R-41 - Mivar VAR; Milano
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 135 x 140 mm / 19.7 x 5.3 x 5.5 inch
Notes

Ingresso per giradischi e registratore.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 33'300.00 ITL
Mentioned in Catalogo ANIE (1970-71, p. 78)
Literature/Schematics (1) Antique Radio Magazine n.78, May-June 2007, page 6. Written in Italian.

Model page created by Aldo Andreani. See "Data change" for further contributors.
