• Country
• United States of America (USA)

• Manufacturer / Brand
• Monarch Electronics Int. Inc.; North Hollywood, CA

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 346140

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BD6 12AV6 50C5 35W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 220-230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Monarch [220V] - Monarch Electronics Int. Inc.;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 165 x 113 x 110 mm / 6.5 x 4.4 x 4.3 inch

• Notes

• The 117 VAC version is the Monarch (Wedge).

  Made in Japan.



• Author
• Model page created by Maurice Hamm. See "Data change" for further contributors.
