STA-400X

STA-400X; Monarch Electronics (ID = 722209) Radio

STA-400X; Monarch Electronics (ID = 722540) Radio
STA-400X; Monarch Electronics (ID = 589102) Radio
Use red slider bar for more.
STA-400X; Monarch Electronics (ID = 589102) Radio
Monarch Electronics: STA-400X [Radio] ID = 589102 593x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model STA-400X, Monarch Electronics Int. Inc.; North Hollywood, CA:
HiFi Jahrbuch 1967/68

Country:  United States of America (USA)
Manufacturer / Brand:  Monarch Electronics Int. Inc.; North Hollywood, CA
Year: 1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 17: 6BE6 6AU6 6AU6 12AU7 6BA6 6BA6 6AQ8 6AQ8 6AQ8 6GW8 6GW8 6GW8 6GW8 12AX7 12AX7 12AX7 5AR4
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 24 W (unknown quality)
from Radiomuseum.org Model: STA-400X - Monarch Electronics Int. Inc.;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 140 x 340 mm / 16.9 x 5.5 x 13.4 inch
Notes Stereo Receiver with 2 x 12 W (17 W) Pout, DIN connectors, four inputs, 20 - 25.000 Hz, also equivalent european tubes possible.
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Price in first year of sale 985.00 DM
Source of data -- Collector info (Sammler)
Mentioned in HiFi Jahrbuch III 1967/68 Seite 149

Model page created by a member from A. See "Data change" for further contributors.
