- Country
- United States of America (USA)
- Manufacturer / Brand
- Monitoradio; Indianapolis (IN)
- Year
- 1959 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 143267
-
- alternative name: Radio Apparatus Corp.; Indianap.
Sams Photofact.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: M-160 - Monitoradio; Indianapolis IN
- Shape
- Chassis only or for «building in»
- Notes
- Battery operated mobile FM receiver. Sams photofact set 480 folder 7 date 4-60 features the Monitoradio models M-40 and M-160 as the same schematic.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 480 folder 7 date 4-60)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
