For model Airline 62-103 Order= 562 A 103, Montgomery Ward & Co. (Wards, Airline); Chicago, IL:
Airline 62-103

Country:  United States of America (USA)
Manufacturer / Brand:  Montgomery Ward & Co. (Wards, Airline); Chicago, IL
Brand

Airline or Air-Line
Year: 1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6D6 6C6 6D6 37 37 42 80
Main principle Superhet with RF-stage; ZF/IF 175 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW), Police, sometimes also early TV (75-200m).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Airline 62-103 Order= 562 A 103 - Montgomery Ward & Co. Wards,
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 16 x 17.25 x 12 inch / 406 x 438 x 305 mm
Notes

Wave bands: broadcast and police. Sold with Airline brand ("Airline 62-103)"). Information from Rider's 4-14 and 4-15 indicate ONLY BC band.

Price in first year of sale 29.50 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 4 = ca. 1934 and before
Mentioned in Rider's 4-14, 4-15
Literature/Schematics (1) Cathedral & Tombstone Radios (page 44.)
Literature/Schematics (2) Table Top Radios Vol. 4 Stein 2003 (page 44.)
Literature/Schematics (3) Montgomery Ward Catalogs (Wards, Airline) (Spring & Summer 1934 page 212)
