10VT24R Ch= TS-14B

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1950
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 234945

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 19
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 117 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
  • Power out
  • 4 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 10VT24R Ch= TS-14B - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Tablemodel, with any shape - general.
  • Notes

  • The Motorola 10VT24R is a 10" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis TS-14B and picture tube 10BP4. Table model with Red Mahogany wooden cabinet. Has Qty(2) Selenium Rectifiers used for power supply rectification and Qty(1) germanium diode video detector.

    This model is part of a series of TVs produced by Motorola using the TS-14, TS-23, and TS-52 chassis.  According to Rider TV vol. 5, the TS-14 chassis was used in 10 inch sets with 10BP4 CRT.  The TS-23 chassis was used in 12 inch sets with 12LP4 CRT, and is identical to the TS-14 chassis except for the high voltage transformer.  The TS-52 chassis was used in 16 inch sets with 16AP4 CRT, and is similar to the TS-14 and TS-23 chassis, except for the high voltage transformer, addition of a second 6BQ6 horizontal output tube, and the use of 25L6GT for the vertical output tube.

    There are variations for each chassis type:  For TS-14A and TS-23A, the 3rd IF tube was changed from 6AU6 to 6AG5.  For TS-14B and TS-23B, the video amplifier tube was changed from 6AU6 to 6AH6, and an additional tap was added to the contrast control.  Chassis TS-52 has the same changes as TS-14B and TS-23B.

  • Literature/Schematics (1)
  • Rider TV vol. 5
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Motorola Datasheet 54P7000225)
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
