24K2B Ch= TS-602
Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1954 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 205664
Data taken from Motorola datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- 6BQ7A or 6BZ7 6U8 6CB6 6CB6 6CB6 12BY7 12AU7 12AU7 6AU6 6AL5 6AV6 6V6GT 6CS6 6SN7GT 6BX7 6SN7GT 6CD6G 6AU4GT 1B3GT 24CP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 inch = 25.4 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 24K2B Ch= TS-602 - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Console with any shape - in general
- Notes
-
Motorola model 24K2B is a 24” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis TS-602, VHF-tuner VTT42 and picture tube 24CP4A. Console model, limed oak.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 233; folder 6, dated 3-54)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
