SH17E Ch= HS-764

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1959
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 78389

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 34 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: SH17E Ch= HS-764 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • The Motorola Model SH17E is an AC operated 5 Tube portable stereo Phono Amplifier and a 4 Speed Automatic Record Changer. Uses chassis HS-764. Cabinet color is Black. This model has Qty(2) 6" PM speakers and Qty(2) 4" PM speakers. Uses Record Changer VM20RC. Sams photofact set 489 folder 15 date 6-60 features the Motorola models SH17E, SH17GL, SH17N, SH17S with chassis HS-764 and the models SK22B, SK22M with chassis HS-766 as the same schematic.
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 20, 1960
  • Literature/Schematics (2)
  • - - Manufacturers Literature
  • Author
  • Model page created by Trev Levick. See "Data change" for further contributors.
