VF102A Ch= HS-137 & TS-7

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1948/1949
  • Category
  • Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
  • Radiomuseum.org ID
  • 163808

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • -Loudspeaker incorporated, but system not known.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: VF102A Ch= HS-137 & TS-7 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 37.75 x 39.5 x 22.5 inch / 959 x 1003 x 572 mm
  • Notes

  • Motorola VF102A;
    10" round CRT b/w TV with US FCC standard 13 channel VHF I/III tuner, AM/FM radio & record changer.

    See also the other Motorola models VF102: model VF102, model VF102A or model VF102C.

  • Source of data
  • - - Manufacturers Literature
  • Literature/Schematics (3)
  • Motorola Folder D1237 for 1949.
