For model MAS82, Mullard Wireless, London (see also Mullard Radio Valve):
Ebay UK auction item no 311858277125 seller palm08

Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH3 EF9 EBL1 AZ1
Main principle Superheterodyne (common); ZF/IF 470 kHz; 1 AF stage(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 100-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: MAS82 - Mullard Wireless, London see
Material Bakelite case
Notes This set is a Mullard variant of the Philips 206A. The Philips schematic can be used.
Literature/Schematics (1) Information from Trader Index & sheet 478.

Model page created by Keith Staines. See "Data change" for further contributors.
