MUS3; Mullard Wireless, (ID = 2288967) Radio
Select picture or schematic to display from thumbnails on the right and click for download.
Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: FC4 VP4B 2D4A PenA4 DW2_Mullard
Main principle Superheterodyne (common); ZF/IF 128 kHz; 1 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Power type and voltage AC/DC-set / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Model: MUS3 - Mullard Wireless, London see
Material Wooden case
Shape Tablemodel, low profile (big size).

This set is the same as the MAS3 (AC mains). Except it has an additional unit, a DC to AC vibratory converter of type  28.891.460.

Price in first year of sale 13.00 GBP
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (594 & 726)

Model page created by Peter Hoddow. See "Data change" for further contributors.
