MUS-253

MUS-253; Mullard Wireless, (ID = 1053058) Radio

MUS-253; Mullard Wireless, (ID = 1053069) Radio

MUS-253; Mullard Wireless, (ID = 1053059) Radio
MUS-253; Mullard Wireless, (ID = 804960) Radio MUS-253; Mullard Wireless, (ID = 814081) Radio
Use red slider bar for more.
MUS-253; Mullard Wireless, (ID = 804960) Radio
Mullard Wireless,: MUS-253 [Radio] ID = 804960 520x376
Select picture or schematic to display from thumbnails on the right and click for download.
For model MUS-253, Mullard Wireless, London (see also Mullard Radio Valve):
My own collection.

Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1955 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: MUS-253 - Mullard Wireless, London see
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 310 x 210 x 155 mm / 12.2 x 8.3 x 6.1 inch
Notes Brown bakelit with red dial.
Net weight (2.2 lb = 1 kg) 3.250 kg / 7 lb 2.5 oz (7.159 lb)

Model page created by Antonio Dias Rodrigues. See "Data change" for further contributors.



All listed radios etc. from Mullard Wireless, London (see also Mullard Radio Valve)
Here you find 139 models, 107 with images and 57 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
