Master 60 Ch= 521
Mullard Radio Company (Australia) Ltd.; Sydney
- Country
- Australia
- Manufacturer / Brand
- Mullard Radio Company (Australia) Ltd.; Sydney
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 164475
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Master 60 Ch= 521 - Mullard Radio Company
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 265 x 360 x 190 mm / 10.4 x 14.2 x 7.5 inch
- Notes
- Uses same chassis as Airzone model 560.
- Price in first year of sale
- 20.00 Aus£
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. I
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
