B837; Murphy Radio Ltd.; (ID = 2623350) Radio
Murphy Radio Ltd.;: B837 [Radio] ID = 2623350 1400x1147
Select picture or schematic to display from thumbnails on the right and click for download.
For model B837, Murphy Radio Ltd.; Welwyn Garden City

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF115 AF116 AF116 OC71 OC81D OC81 OC81
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: B837 - Murphy Radio Ltd.; Welwyn
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 15.875 x 8.625 x 4.625 mm / 0.6 x 0.3 x 0.2 inch
Notes

A battery powered portable nine transistor AM/FM radio covering LW (1070 - 1900 metres), MW (187 - 570 metres), MW Bandspread (187 - 210 metres) and VHF (87.5 - 100 MHz). Sockets for earphone and car aerial. PP9 battery. Elliptical loudspeaker 7 x 4 inch.

Net weight (2.2 lb = 1 kg) 6.5 lb (6 lb 8 oz) / 2.951 kg
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) - - Manufacturers Literature (Murphy Service Instructions TP1675)
Literature/Schematics (3) ERT Service Chart 1704 dated July 17 1969

Model page created by Howard Craven. See "Data change" for further contributors.
