• Year
  • 1951
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 96895

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Number of Transistors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: V200 - Murphy Radio Ltd.; Welwyn
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • 12" 405 Line TV Table Model with VHF Band I Tuner for one channel only, (via 5 changeable RF units), Chassis in 4 parts - fixed like a star around the Pic. tube.
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
