For model Taschenradio G1030FM, Nachrichtenelektronik Greifswald, VEB (NEG); Greifswald (Ostd.)

Country:  Germany
Manufacturer / Brand:  Nachrichtenelektronik Greifswald, VEB (NEG); Greifswald (Ostd.)
Year: 1987 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 2: SF235 SF235 A283D
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Taschenradio G1030FM - Nachrichtenelektronik
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 150 x 80 x 35 mm / 5.9 x 3.1 x 1.4 inch
Notes Empfängerschaltkreis A283D, FM ZF-Verstärker 10,7 MHz, ein piezokeramisches Filter; von den 7 FM-Kreisen sind 2 abstimmbar.
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 150.00 DM
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Nachrichtenelektronik Greifswald, VEB (NEG); Greifswald (Ostd.)
Here you find 4 models, 4 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
