Compact Disc Player 5425

Compact Disc Player 5425; NAD, New Acoustic (ID = 2381467) R-Player Compact Disc Player 5425; NAD, New Acoustic (ID = 2381468) R-Player
Compact Disc Player 5425; NAD, New Acoustic (ID = 2381469) R-Player Compact Disc Player 5425; NAD, New Acoustic (ID = 2381475) R-Player
Use red slider bar for more.
Compact Disc Player 5425; NAD, New Acoustic (ID = 2381467) R-Player
NAD, New Acoustic: Compact Disc Player 5425 [R-Player] ID = 2381467 1400x400
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Disc Player 5425, NAD, New Acoustic Dimension; Ontario:
Ebay.uk auction item 233109964460 seller thingmebobsuk

Country:  Canada
Manufacturer / Brand:  NAD, New Acoustic Dimension; Ontario
Year: 1988–1991 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 120 or 220 or 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact Disc Player 5425 - NAD, New Acoustic Dimension;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 420 x 90 x 260 mm / 16.5 x 3.5 x 10.2 inch
Notes

A stereo hi-fi Compact Disc Player with remote control. Memory for 16 tracks. Line out RCA sockets.

Specification
Digital to Analogue conversion .............:  MASH 18 bit resolution
Digital Filter .......................................:  4 times oversampled linear phase with 18                                                                bit coefficients
Analog Filter ......................................:  5 pole active
CD Mechanism ..................................:  Sony KSS-210A
Frequency response ...........................:  5Hz to 20kHz -0, -0.5dB
Signal to Noise Ratio A Weighted ........:  110dB de-emphasis on, 106dB de-emphasis off
THD (at 0dB, 1 kHz) ...........................:  0.0025%
Intermodulation Distortion (19&20kHz) ..:  < -100dB
Dynamic Range .................................:  98dB
Channel separation ............................:  > 100dB (1 kHz), > 80dB (10 kHz)
Output Level/Impedance .....................:  2 V rms / 120Ω

Versions/Power Requirements
120 V AC 60Hz
220 V AC 50Hz
240 V AC 50Hz

Similar to the NAD 5420 Compact Disc Player which does not have remote control.

Designed and Engineered in London
Made in Taiwan

Net weight (2.2 lb = 1 kg) 4.1 kg / 9 lb 0.5 oz (9.031 lb)
Mentioned in - - Manufacturers Literature (1988 Audio Products Highlights catalogue)
Literature/Schematics (1) - - Manufacturers Literature (NAD Service Manual for the 5420/5425 Compact Disc Players dated 1991)
