For model Stereo Cassette Deck 6340, NAD, New Acoustic Dimension; Ontario:
Ebay Auction

Country:  Canada
Manufacturer / Brand:  NAD, New Acoustic Dimension; Ontario
Year: 1988 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC)
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Cassette Deck 6340 - NAD, New Acoustic Dimension;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 420 x 122 x 271 mm / 16.5 x 4.8 x 10.7 inch
Notes

NAD Frontloding Stereo Cassette Deck Model 6340.
Two Head Monitor Series Cassette Deck
Tape Type: type I, Cr02, Metal
Noise Reduction: B, C, HX Pro
Frequency Response: 35Hz to 18kHz (Metal tape)
Signal to Noise Ratio: 70dB (dolby C)
Wow and Flutter: 0.05%
Total Harmonic Distortion: 1.2%
Input: 40mV (line)
Output: 0.5V (line)
3 Digit Mechanical Tape Counter
Play Trim

Power Requirements:
Model:
A - USA, A1 - Canada, A2 - Taiwan - 120VAC 60Hz, 22 Watts
B - U.K., B1 - Australia/N.Z., C - Europe&Others, C1 - W.Germany, C2 - G.P.M. - 220-240VAC 50Hz, 22 Watts



Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Mentioned in - - Manufacturers Literature (Service Manual)
