• Country
• Canada

• Manufacturer / Brand
• NAD, New Acoustic Dimension; Ontario

• Year
• 1987

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 207526

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 120; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 80 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Power Amplifier 2240 PE - NAD, New Acoustic Dimension;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 420 x 108 x 380 mm / 16.5 x 4.3 x 15 inch

• Notes
• Stereo Vollverstärker mit 2x 40 Watt Sinus an 8 Ohm.

• Net weight (2.2 lb = 1 kg)
• 6.460 kg / 14 lb 3.7 oz (14.229 lb)

• Source of data
• -- Original prospect or advert

• Mentioned in
• Produktkatalog 1987 - " Die NAD Classic Serie"

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
