TV-5500 2B2

TV-5500; NEC Corporation, (ID = 2034205) TV Radio TV-5500; NEC Corporation, (ID = 2034209) TV Radio
TV-5500; NEC Corporation, (ID = 2034210) TV Radio TV-5500; NEC Corporation, (ID = 2034211) TV Radio
TV-5500; NEC Corporation, (ID = 2034206) TV Radio TV-5500; NEC Corporation, (ID = 2034207) TV Radio
TV-5500; NEC Corporation, (ID = 2034208) TV Radio TV-5500; NEC Corporation, (ID = 2034212) TV Radio
TV-5500; NEC Corporation, (ID = 2034213) TV Radio TV-5500; NEC Corporation, (ID = 2034214) TV Radio
Use red slider bar for more.
TV-5500; NEC Corporation, (ID = 2034205) TV Radio
NEC Corporation,: TV-5500 [TV Radio] ID = 2034205 1400x672
Select picture or schematic to display from thumbnails on the right and click for download.
For model TV-5500 2B2, NEC Corporation, Nippon Electric Co. Ltd. (Nippon Denki); Tokyo:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Japan
Manufacturer / Brand:  NEC Corporation, Nippon Electric Co. Ltd. (Nippon Denki); Tokyo
Year: 1973 ?? Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 12 / D: 8×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TV-5500 [2B2] - NEC Corporation, Nippon
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes s/w-TV mit CCIR B/G VHF/UHF Tuner; 3-Band-AM/FM Radio; Kassetten-Kombi-Gerät; deutsche Beschriftung. Externe Stromversorgung mit 12 V möglich.
Collectors' prices
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
