For model US (УС) PR-4 (ПР-4) PR-4V (ПР-4В), Nizhegorodsky Lenin Works (NITEL):
tin box above consists home built power supply, not original!

Country:  Soviet Union
Manufacturer / Brand:  Nizhegorodsky Lenin Works (NITEL)
Year: 1948–1956 perfect model Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 8: 6К7 6К7 6К7 6К7 6К7 6К7 6А7 6Х6
Main principle Superhet with RF-stage; ZF/IF 112 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Storage and/or dry batteries / 25,5 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: US PR-4 PR-4V - Nizhegorodsky Lenin Works
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 320 x 135 x 180 mm / 12.6 x 5.3 x 7.1 inch
Notes

Information by member Valery Gromov: "This PR-4P post-war model is existant since 1948, made by Radio Works No. 197 of Gorky-city (nowadays Nizhny Novgorod). The civil name of the factory was "Lenin Radio Works of Gorky-city" (Gorkovsky Radiozavod named after Lenin).

There is the two quite different models Air Force model US-4, using metal tubes with 6.3V filaments, and the US-4S infantry model, using glass tubes with 2V filaments. Both US-4 and US-4S were manufactured at Novosibirk Radio Works No. 590 (civil name "Novosibirsky Electrosignal") starting from 1943. It is unclear why there was already an US-4 designation for the HRO copycat in 1940 that was manufactured in Riga for the Red Army but was soon taken over by the Germans - and can now be found with the Wehrmacht Reichsadler."

Old information: AM/CW-receiver for millitary/airborne use, coverage from 0.17 to 12 MHz in five ranges. Needs Hi-Z headset. At first time radio set named US (universal superheterodyne),US-3 (in 1942), after WW2 named US-P, only last models named as PR-4 (P, R, V). Till 1941 produced in one of Moscow factories. After 1941 manufactured in Nizhegorodsk. Used as receiver-block in radio-stations RAF, RSB etc. Used motor type voltage conversion unit(Dynamotor/umformer) type RUK-300V (see foto). It works at 25,5V and supply radio tubes 6,3V (heating) and 200-220V (anode).

Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)

Model page created by a member from D. See "Data change" for further contributors.



All listed radios etc. from Nizhegorodsky Lenin Works (NITEL)
Here you find 12 models, 12 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
