Siete (7) Mares NT119

Siete Mares NT119; Noblex Argentina SA; (ID = 526121) Radio

Siete Mares NT119; Noblex Argentina SA; (ID = 526126) Radio
Siete Mares NT119; Noblex Argentina SA; (ID = 318503) Radio Siete Mares NT119; Noblex Argentina SA; (ID = 318504) Radio
Siete Mares NT119; Noblex Argentina SA; (ID = 318505) Radio Siete Mares NT119; Noblex Argentina SA; (ID = 318506) Radio
Siete Mares NT119; Noblex Argentina SA; (ID = 323091) Radio Siete Mares NT119; Noblex Argentina SA; (ID = 473521) Radio
Siete Mares NT119; Noblex Argentina SA; (ID = 473522) Radio Siete Mares NT119; Noblex Argentina SA; (ID = 1061149) Radio
Siete Mares NT119; Noblex Argentina SA; (ID = 1811076) Radio Siete Mares NT119; Noblex Argentina SA; (ID = 1811077) Radio
Use red slider bar for more.
Siete Mares NT119; Noblex Argentina SA; (ID = 318503) Radio
Noblex Argentina SA;: Siete Mares NT119 [Radio] ID = 318503 424x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Siete (7) Mares NT119, Noblex Argentina SA; Nobleza Radio; Buenos Aires

Country:  Argentina
Manufacturer / Brand:  Noblex Argentina SA; Nobleza Radio; Buenos Aires
Year: 1972 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 19: 2A407 BF194 BF195 BF195 2A258 BF195 BF195 BF195 2A258 BF195 BC148 AC127 AC128 AC127 AC128 BF199 2A407 BF199 AC128 1N60 1N60 BZY83 1N60 1N60 1N60 1S352 1A757 1S1944 1S1944
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Siete Mares NT119 - Noblex Argentina SA; Nobleza
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 340 x 255 x 100 mm / 13.4 x 10 x 3.9 inch
Notes

Este modelo NT119 es parecido al modelo Noblex NT118 pero tiene FM. 10 diodos. 19 transistores, en la versión nueva de la fuente con 20 transistores.

6 bandas:
  - OL (OM)
  - 80-160 m
  - 49 m
  - 31 m
  - 25-19 m
  - FM (88-108 MHz)


Model NT119 is equal to model Noblex NT118, but includes FM as an additional wave band.

It is equipped with 19 transistors and 10 diodes. Up from a certain serial number (number not specified) the model counts 20 transistors, as the power supply unit is using an additional transistor AC128.

Wave bands:
  - OL (MW)
  - 80-160 m
  - 49 m
  - 31 m
  - 25-19 m
  - FM (88-108 MHz).





Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)

Model page created by Mario Bermejo. See "Data change" for further contributors.
