• Year
  • 1955
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 101078
    • Brand: Noroton

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Netzgerät NG-2 - Nogoton, Norddeutsche
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 65 x 80 x 70 mm / 2.6 x 3.1 x 2.8 inch
  • Notes
  • Stromversorgung für Nogoton-Bausteine. 6,3 V~/1 A, 7,5 V~/0,3 A und 200 V=/30 mA. Passend für UK 12642/55 Z-Spezial

    Preis 1956: 22 DM
    Preis 1959: 25 DM

  • Price in first year of sale
  • 22.00 DM
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Otto Frosinn. See "Data change" for further contributors.
