K3We

K3We; Nora; Berlin (ID = 21982) Radio
K3We; Nora; Berlin (ID = 59859) Radio K3We; Nora; Berlin (ID = 100253) Radio
K3We; Nora; Berlin (ID = 373227) Radio K3We; Nora; Berlin (ID = 373229) Radio
K3We; Nora; Berlin (ID = 373230) Radio K3We; Nora; Berlin (ID = 373231) Radio
K3We; Nora; Berlin (ID = 2228187) Radio
Use red slider bar for more.
K3We; Nora; Berlin (ID = 59859) Radio
Nora; Berlin: K3We [Radio] ID = 59859 491x327
Select picture or schematic to display from thumbnails on the right and click for download.
For model K3We, Nora; Berlin

Country:  Germany
Manufacturer / Brand:  Nora; Berlin
Year: 1928–1930 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: REN1004 REN1004 RE134 RGN1500
Main principle TRF with regeneration; 2 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 120-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: K3We - Nora; Berlin
Material Wooden case
Dimensions (WHD) 355 x 210 x 170 mm / 14 x 8.3 x 6.7 inch
Notes Glimmerdrehko; 1500=Pat.Raytheon
Price in first year of sale 180.00 RM
Collectors' prices
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Röhren in FS-Bestückungstabellen
Mentioned in Funkgeschichte der GFGF (8332)
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"


All listed radios etc. from Nora; Berlin
Here you find 614 models, 530 with images and 336 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
