Super 200-9 Ch= 5210; Nordmende, (ID = 12074) Radio
Nordmende,: Super 200-9 Ch= 5210 [Radio] ID = 12074 770x580
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super 200-9 Ch= 5210, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UF85 UCH81 UF85 UABC80 UL41
Semiconductors (the count is only for transistors) E220C80
Main principle Superhet with RF-stage; ZF/IF 473/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage AC/DC-set / 110; 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Super 200-9 Ch= 5210 - Nordmende, Norddeutsche Mende-
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 300 x 200 x 145 mm / 11.8 x 7.9 x 5.7 inch
Notes

Nordmende Super 200-9 wurde im Jahrgang 1953/54 als Elektra angeboten.

Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Price in first year of sale 198.00 DM
External source of data Erb
Source of data Kat.d.Rundf.GrossH.1952/53
Literature/Schematics (1) -- Original-techn. papers.
