• Year
  • 1968–1970
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 125929

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 14
  • Number of Transistors
  • 33
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 38900/5500 kHz; 2 AF stage(s)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 3 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Color 1900 - Nordmende, Norddeutsche Mende-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 700 x 465 x 490 mm / 27.6 x 18.3 x 19.3 inch
  • Notes
  • Röhren teilweise mehrfach vorhanden. 56 Dioden, 8 Si-Gleichrichter. 48cm Farbfernseh-Tischgerät. VHF/UHF Tuner mit Dioden-Abstimmung.
  • Net weight (2.2 lb = 1 kg)
  • 36 kg / 79 lb 4.7 oz (79.295 lb)
  • Price in first year of sale
  • 1,745.00 DM
  • Author
  • Model page created by Bernhard Nagel. See "Data change" for further contributors.
