• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 9999/9999

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 110112

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• PCC88 PCF801 EF183 EF183 EF80 PCL84 EF80 PCL86 ECH84 ECH84 ECC82 EAA91 PCL85 PL500 PY88 DY86 A59-11W or A59-12W

• Number of Transistors
• 2

• Semiconductors
• AF139 AF139

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Dublette ID =31008 - Nordmende, Norddeutsche Mende-

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 1285 x 935 x 475 mm / 50.6 x 36.8 x 18.7 inch

• Notes

• Rundfunk-Chassis 4/633, 6/10 Kreise, LMKU;
  Phono-Chassis = Dual 1007.

• Net weight (2.2 lb = 1 kg)
• 84.5 kg / 186 lb 2 oz (186.123 lb)

• Price in first year of sale
• 2,765.00 DM

• Source of data
• Handbuch VDRG 1964/1965

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
