Nordmende,: Transita de Luxe UML D030 Ch= 3/603 [Radio] ID = 1801956 933x797
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transita de Luxe UML D030 Ch= 3/603, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 OC615 AF105 AF105 AF105 OC75 OC71 OC74 OC74 OA160 AA112 AA112
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Transita de Luxe UML D030 Ch= 3/603 - Nordmende, Norddeutsche Mende-
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 170 x 80 mm / 9.4 x 6.7 x 3.1 inch
Notes

UKW: 86,7 - 104,5 MHz
MW: 515 - 1650 kHz
LW: 145 - 260 kHz

Zusätzliche Antennenbuchse für Betrieb an Autoantennen

5 Farben: bordeauxrot, deltagrün, golfblau, schwarz oder cubanaweiß.

Net weight (2.2 lb = 1 kg) 2.1 kg / 4 lb 10 oz (4.626 lb)
Price in first year of sale 248.00 DM
Source of data Handbuch VDRG 1963/1964 / Radiokatalog Band 1, Ernst Erb
Mentioned in Handbuch RFP 1963
Literature/Schematics (1) -- Original-techn. papers.
