For model Transita-Export UKW bis 108 MHz, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
FM range up to 108 MHz

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: OC615 OC615 OC614 AF105 AF105 OC75 OC71 OC74 OC74 OA160 OA172 OA172
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; Export model
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 3R12: 2 × 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Transita-Export [UKW bis 108 MHz] - Nordmende, Norddeutsche Mende-
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 170 x 80 mm / 9.4 x 6.7 x 3.1 inch
Notes

UKW: 87,5 - 108 MHz
LW: 145 - 260 kHz
MW: 515 - 1650 kHz
KW: 5900 - 12500 kHz

Siehe auch Transita-Export Z032 Ch= 2/603KL  mit UKW bis 104 MHz.

Net weight (2.2 lb = 1 kg) 2.4 kg / 5 lb 4.6 oz (5.286 lb)

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
