Normameter E2

Normameter E2; NORMA Messtechnik (ID = 709592) Equipment

Normameter E2; NORMA Messtechnik (ID = 709593) Equipment

Normameter E2; NORMA Messtechnik (ID = 709595) Equipment

Normameter E2; NORMA Messtechnik (ID = 709589) Equipment

Normameter E2; NORMA Messtechnik (ID = 709590) Equipment

Normameter E2; NORMA Messtechnik (ID = 709571) Equipment

Normameter E2; NORMA Messtechnik (ID = 709572) Equipment

Normameter E2; NORMA Messtechnik (ID = 709573) Equipment

Normameter E2; NORMA Messtechnik (ID = 709574) Equipment

Normameter E2; NORMA Messtechnik (ID = 709575) Equipment
Normameter E2; NORMA Messtechnik (ID = 2268542) Equipment Normameter E2; NORMA Messtechnik (ID = 477559) Equipment
Normameter E2; NORMA Messtechnik (ID = 477560) Equipment Normameter E2; NORMA Messtechnik (ID = 477561) Equipment
Use red slider bar for more.
Normameter E2; NORMA Messtechnik (ID = 2268542) Equipment
NORMA Messtechnik: Normameter E2 [Equipment] ID = 2268542 1400x704
Select picture or schematic to display from thumbnails on the right and click for download.
For model Normameter E2, NORMA Messtechnik GmbH, Wien

Country:  Austria
Manufacturer / Brand:  NORMA Messtechnik GmbH, Wien
Year: 1965 ?? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Dry Batteries / 2 x 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Normameter E2 - NORMA Messtechnik GmbH, Wien
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 265 x 102 x 105 mm / 10.4 x 4 x 4.1 inch
Notes Vielfachmessgerät Normameter E2.
Spannungsbereich: AC/DC 100 mV bis 3000 V;
Strombereich: DC: 40 µA bis 10 A, AC: 0,3 mA bis 10 A;
Widerstandsbereich: 1 Ohm bis 50 MOhm;
Kapazitätsbereich: 10 pF bis 50 µF.
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data - - Data from my own collection

Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
