2214

2214; Novak also Pontiac; (ID = 893463) Television

2214; Novak also Pontiac; (ID = 893464) Television

2214; Novak also Pontiac; (ID = 893465) Television

2214; Novak also Pontiac; (ID = 893466) Television

2214; Novak also Pontiac; (ID = 893467) Television

2214; Novak also Pontiac; (ID = 893468) Television
Use red slider bar for more.
2214; Novak also Pontiac; (ID = 893463) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Belgium
Manufacturer / Brand:  Novak (also Pontiac); Bruxelles
Year: 1961 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: PCC189 PCF86 EF183 EF184 EF184 PCF82 PCF82 PCL84 EF183 EF184 EAA91 PCL86 EBF89 ECH83 PCC85 PCF80 PL500 PY88 DY87 ECC82 AW59-90 or 23VP4
Semiconductors (the count is only for transistors) OA72 OA72 OA72 OA70 OA70 OA81 OA81 OA81 E50C5 E50C5
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: 2214 - Novak also Pontiac; Bruxelles
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes Unit uses 8 additional germanium diodes and 2 selenium diodes.
4 Standards: 819F, 819B, 625B, 625 CCIR
2 loudspeakers, 1 is tweeter.
VHF only, UHF in option.
Source of data -- Original-techn. papers.

Model page created by Dirk Bladt. See "Data change" for further contributors.
