- Country
- Netherlands
- Manufacturer / Brand
- NSF Nederlandsche Seintoestellen Fabriek, Hilversum
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 87761
Unit after restoration, powered up
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110,127, 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: HV1501U - NSF Nederlandsche
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 290 x 200 x 170 mm / 11.4 x 7.9 x 6.7 inch
- Notes
- Scale bulb 8097 D 00
- Price in first year of sale
- 158.00 Hfl
- Source of data
- - - Data from my own collection
- Other Models
-
Here you find 160 models, 118 with images and 85 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from NSF Nederlandsche Seintoestellen Fabriek, Hilversum
Collections
The model is part of the collections of the following members.
Forum contributions about this model: NSF Nederlandsche: HV1501U
Threads: 1 | Posts: 1
This radio is very similar to the Philips model BX221U. I even think that the BX221U has been manufactured in the NSF Factory.
Georges Van Campenhout † 28.4.22, 25.May.06
