For model Surcouf 54 Front White, Océanic, ITT Océanic; Paris

Country:  France
Manufacturer / Brand:  Océanic, ITT Océanic; Paris
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6AU6 ECH81 EBF80 6AU6 EM34 EL84 EZ80
Main principle Superhet with RF-stage; 2 AF stage(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Surcouf 54 [Front White] - Océanic, ITT Océanic; Paris
Material Various materials
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 480 x 310 x 215 mm / 18.9 x 12.2 x 8.5 inch
Notes

Version with front in white and dial beije and green.

Dial lamps: 4x 8024D (6,3V/0,3A).

Mentioned in -- Collector info (Sammler)

Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
