RC Oscillator RCO-6K

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597118) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597119) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597120) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597121) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597122) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597123) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597124) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597126) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597127) Equipment

RC Oscillator RCO-6K; Oltronix AB; (ID = 1597128) Equipment
RC Oscillator RCO-6K; Oltronix AB; (ID = 1596927) Equipment
Use red slider bar for more.
RC Oscillator RCO-6K; Oltronix AB; (ID = 1596927) Equipment
Oltronix AB;: RC Oscillator RCO-6K [Equipment] ID = 1596927 933x980
Select picture or schematic to display from thumbnails on the right and click for download.
For model RC Oscillator RCO-6K, Oltronix AB; Vällingby:
Source: Instruction Manual RCO-6K

Country:  Sweden
Manufacturer / Brand:  Oltronix AB; Vällingby
Year: 1964 Category: Service- or Lab Equipment
Valves / Tubes 5: EF80 EF80 UC92 UCL82 UCL82
Main principle none
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 127; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: RC Oscillator RCO-6K - Oltronix AB; Vällingby
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 218 x 234 x 300 mm / 8.6 x 9.2 x 11.8 inch
Notes

Frequency range: 3Hz - 300kHz in
5 ranges:
3-30Hz, 30-300Hz, 300-3000Hz, 3-30kHz, 30-300kHz
Calibration accuracy: +-2%
Output Voltage: 0-125V in 6 ranges
0-1.25mV; 0-12.5mV, 0-125mV, 0-1.25V, 0-12.5V, 0-125V
Power Output: 1W 20Hz-75kHz range matched to load impedancees: 5, 50, 600 and 8000 ohms
Distortion: 20-100 Hz 1,5%; 0.1-20kHz <1%







Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Mentioned in -- Original-techn. papers.

Model page created by Pius Steiner. See "Data change" for further contributors.
