6A-606

6A-606 ; Olympic Radio & (ID = 399650) Radio

6A-606 ; Olympic Radio & (ID = 399651) Radio
6A-606 ; Olympic Radio & (ID = 2031173) Radio 6A-606 ; Olympic Radio & (ID = 2031174) Radio
6A-606 ; Olympic Radio & (ID = 2031175) Radio 6A-606 ; Olympic Radio & (ID = 2031176) Radio
6A-606 ; Olympic Radio & (ID = 2031177) Radio 6A-606 ; Olympic Radio & (ID = 2031178) Radio
6A-606 ; Olympic Radio & (ID = 2031179) Radio
Use red slider bar for more.
6A-606 ; Olympic Radio & (ID = 2031173) Radio
Olympic Radio &: 6A-606 [Radio] ID = 2031173 1400x1021
Select picture or schematic to display from thumbnails on the right and click for download.
For model 6A-606, Olympic Radio & Television, Inc.; New York (NY):
Olympic Model 6A-606 front, missing knobs.

Country:  United States of America (USA)
Manufacturer / Brand:  Olympic Radio & Television, Inc.; New York (NY)
Year: 1948 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 1LN5 1LA6 1LN5 1LH4 3Q5GT 35Z5GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / AC-DC 105-125 / 2 x 45 & 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 6A-606 - Olympic Radio & Television,
Shape Portable set > 8 inch (also usable without mains)
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 16 = ca. 1948 and before
