Molibden R-154-2M {Р-154-2М}; Omsk Kozitsky (ID = 1779021) Receiver-C
Omsk Kozitsky: Molibden R-154-2M {Р-154-2М} [Receiver-C] ID = 1779021 1400x1524
Select picture or schematic to display from thumbnails on the right and click for download.
For model Molibden R-154-2M {Р-154-2М}, Omsk Kozitsky Devices Works

Country:  Soviet Union
Manufacturer / Brand:  Omsk Kozitsky Devices Works
Year: 1963–1978 Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 42: 12Ж1Л 6Х2П СГ2С
Main principle Superhet, double/triple conversion
Wave bands Short Wave (SW only)
Details
Power type and voltage AC/DC-set / 127;220 / 160/13 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Molibden R-154-2M {Р-154-2М} - Omsk Kozitsky Devices Works
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 630 x 690 x 480 mm / 24.8 x 27.2 x 18.9 inch
Notes Hight class profesional military AM, CW receiver. Widely used in Soviet and Warzaw allies armies. Often in mobile radio-station complex R-118BM.
Coverage 1 - 12 MHz in three ranges. Possible three tuning modes - fixed frequencies tune, precision tune in short range and wide range total scan.
Phone and two CW contacts at same time. Hight precision frequency quartz gauge in schemat.
Receiver fitted for very low temperature and intensive vibration. Set is quadripartite, four separate blocks sets-in sace. About 5000 units series R-154 receivers produced at all time.
Tubes: 12j1l(36), 6h2p(5),sg2s(1).
Net weight (2.2 lb = 1 kg) 95 kg / 209 lb 4 oz (209.251 lb)
Collectors' prices
Source of data -- Schematic
Mentioned in - - Data from my own collection (V.I.Shapkin, "The Red Ears", Moscow 2003)
