Boreal E 1002
Optimus; Gerona
- Country
- Spain
- Manufacturer / Brand
- Optimus; Gerona
- Year
- 1962
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 116891
-
- alternative name: Pla Hermanos y Cía
Datos del manual de instrucciones fabricante
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 60 W (80 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Boreal E 1002 - Optimus; Gerona
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 327 x 120 x 365 mm / 12.9 x 4.7 x 14.4 inch
- Notes
- Entradas:4 Para Micrófono de cristal. 1 Para Pick-up ó Cinta Magnetofónica. Impedancias de salida:40, 83, 100, 125, 250, y 500 Ohm.
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
