332; Orion; Budapest (ID = 97967) Radio
Orion; Budapest: 332 [Radio] ID = 97967 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model 332, Orion; Budapest

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6BE6 6BA6 6AT6 6X4 EM4 6AQ5
Main principle Super-Heterodyne (Super in general); ZF/IF 473.6 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 150, 180, 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 332 - Orion; Budapest
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 485 x 330 x 260 mm / 19.1 x 13 x 10.2 inch
Collectors' prices
Mentioned in Rádiókészülékek Kapcsolásai 1936-56

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.



All listed radios etc. from Orion; Budapest
Here you find 993 models, 849 with images and 355 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
