• Country
• Hungary

• Manufacturer / Brand
• Orion; Budapest

• Year
• 1959–1963

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 183498

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF89 ECL82 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 473,6 kHz

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 19 cm = 7.5 inch

• Power out
• 1.2 W (unknown quality)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: AR321/02 - Orion; Budapest

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 320 x 270 x 250 mm / 12.6 x 10.6 x 9.8 inch

• Notes
• SW1: 2 - 6 MHz; SW2: 6 - 18,2 MHz.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Price in first year of sale
• 1,310.00 HUF

• Source of data
• Radio es Televizio Vevö Keszülekek, 1960-63

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
