AT1651-O

Orion; Budapest

  • Year
  • 1965
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 204205

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Valves / Tubes
  • Number of Transistors
  • 6
  • Semiconductors
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Power out
  • 2 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: AT1651-O - Orion; Budapest
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 720 x 490 x 360 mm / 28.3 x 19.3 x 14.2 inch
  • Notes
  • Speaker: 398×95 mm / 4 Ohm. OIRT 1,2,4,8,9,11,12.
  • Net weight (2.2 lb = 1 kg)
  • 35 kg / 77 lb 1.5 oz (77.093 lb)
  • Price in first year of sale
  • 6,780.00 HUF
  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • Gyurkovics Attila: Televíziójavítás AT651, AT1651. Bp. 1969.
  • Literature/Schematics (4)
  • Műszaki Élet, 1965.
