Channel Konverter UE-100

Channel Konverter UE-100; Orion; Budapest (ID = 1741820) Converter
Channel Konverter UE-100; Orion; Budapest (ID = 703553) Converter Channel Konverter UE-100; Orion; Budapest (ID = 703557) Converter
Channel Konverter UE-100; Orion; Budapest (ID = 703554) Converter Channel Konverter UE-100; Orion; Budapest (ID = 703555) Converter
Channel Konverter UE-100; Orion; Budapest (ID = 703556) Converter Channel Konverter UE-100; Orion; Budapest (ID = 703558) Converter
Channel Konverter UE-100; Orion; Budapest (ID = 703559) Converter Channel Konverter UE-100; Orion; Budapest (ID = 1186597) Converter
Channel Konverter UE-100; Orion; Budapest (ID = 1741822) Converter Channel Konverter UE-100; Orion; Budapest (ID = 2127903) Converter
Use red slider bar for more.
Channel Konverter UE-100; Orion; Budapest (ID = 703553) Converter
Orion; Budapest: Channel Konverter UE-100 [Converter] ID = 703553 933x682
Select picture or schematic to display from thumbnails on the right and click for download.
For model Channel Konverter UE-100, Orion; Budapest:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1967–1969 Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Semiconductors (the count is only for transistors) 1:
Main principle RF Converter/Adapter (not voltage converter)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / 2 × 3 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Channel Konverter UE-100 - Orion; Budapest
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 110 x 40 x 86 mm / 4.3 x 1.6 x 3.4 inch
Notes Coverter from Budapest's 24th channel to 4th channel, OIRT standard, color and b/w broadcast reception. Imp: 240 Ohm, U: DC 6V/2mA, Sound 91,75 MHz, Picture: 85,25 MHz.
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 243.00 HUF
Literature/Schematics (1) Radio es Televizio Vevö keszülekek 1967-69

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
