For model Szimfónia R946F I (1), Videoton; Székesfehérvár:
Thanks for Mr.Sik Béla, Hungary!

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1960–1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 ECH81 EBL21 EZ80 EM80
Main principle Superheterodyne (common); ZF/IF 473,6 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 16 cm = 6.3 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Szimfónia R946F I - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 330 x 250 mm / 19.7 x 13 x 9.8 inch
Notes KW-Bereich 6···18,7 MHz; Ferritantenne. Export: Orion marke embleme!
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 1'460.00 HUF
Source of data - - Data from my own collection
Mentioned in Radio es Televizio Vevö Keszülekek, 1958-59

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
