Stereo HiFi Tuner ST-1025 / HX914K/1

Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 423085) Radio

Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 423086) Radio

Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 2407855) Radio
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 423075) Radio Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 542735) Radio
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 980645) Radio Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 980646) Radio
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 980647) Radio Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 980649) Radio
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 1537558) Radio Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 1537559) Radio
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 1537562) Radio Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 1623620) Radio
Use red slider bar for more.
Stereo HiFi Tuner ST-1025 / HX914K/1; Orion; Budapest (ID = 423075) Radio
Orion; Budapest: Stereo HiFi Tuner ST-1025 / HX914K/1 [Radio] ID = 423075 933x369
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo HiFi Tuner ST-1025 / HX914K/1, Orion; Budapest

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1983 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 18:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo HiFi Tuner ST-1025 / HX914K/1 - Orion; Budapest
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 250 x 56 x 280 mm / 9.8 x 2.2 x 11 inch
Notes FM: OIRT & CCIR. Short wave: 49m. 7 ICs.
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Price in first year of sale 6'500.00 HUF
Source of data - - Data from my own collection

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Orion; Budapest
Here you find 997 models, 852 with images and 364 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
