- Country
- Belgium
- Manufacturer / Brand
- Orthodyne Radio; J. Bonhomme; Liège, Bruxelles
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 323395
radiocollection.be
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 485 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 385 - Orthodyne Radio; J. Bonhomme;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 610 x 310 x 310 mm / 24 x 12.2 x 12.2 inch
- Notes
-
3 wavebands from 16 to 2000 m. Tone control.
Remark: first tube 6A7 is not absolutely certain but probable.
- Price in first year of sale
- 1,990.00 BFR
- Mentioned in
- -- Original prospect or advert (Série 1938)
