G2

G2; Owin; Hannover (ID = 1518479) Radio G2; Owin; Hannover (ID = 1518484) Radio
Use red slider bar for more.
G2; Owin; Hannover (ID = 1518479) Radio
Owin; Hannover: G2 [Radio] ID = 1518479 618x820
Select picture or schematic to display from thumbnails on the right and click for download.
For model G2, Owin; Hannover:
Der Rundfunk-Händler - Aug 1928

Country:  Germany
Manufacturer / Brand:  Owin; Hannover
Year: 1928/1929 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6:
Main principle TRF with regeneration; 1 Special; 2 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: G2 - Owin; Hannover
Material Wooden case
Shape Console with any shape - in general
Notes NF-Verstärker V2 mit E54, Plattenspieler + LS.
Source of data Radio Schnorr 1929 / Radiokatalog Band 1, Ernst Erb
