G6G

G6G; Owin; Hannover (ID = 2508730) Radio G6G; Owin; Hannover (ID = 2508731) Radio
G6G; Owin; Hannover (ID = 2508737) Radio
Use red slider bar for more.
G6G; Owin; Hannover (ID = 2508730) Radio
Owin; Hannover: G6G [Radio] ID = 2508730 1143x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model G6G, Owin; Hannover:
Owin Prospekt

Country:  Germany
Manufacturer / Brand:  Owin; Hannover
Year: 1930/1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RE034s RE034s RE134S RE134S
Main principle TRF with regeneration
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details Record Player (not changer)
Power type and voltage Direct Current supply (DC) / 220 Volt
Loudspeaker Magnetic loudspeaker (reed) of high quality (4 magnet poles).
Power out 1 W (unknown quality)
from Radiomuseum.org Model: G6G - Owin; Hannover
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

Musikschrank für Rundfunk- und Schallplattenwiedergabe für Wechselstrom, Typ G6G. Elektrisches Laufwerk, 1 Watt Endleistung. Dreirohr-Bezirks-Empfänger. Eingebauter 4-poliger Lautsprecher.

Apparat ohne Röhren RM 525,- , dazu 1 Satz Röhren RM 35,-

Siehe auch Owin V25G

Price in first year of sale 560.00 RM
Mentioned in -- Original prospect or advert

Model page created by Richard Winter. See "Data change" for further contributors.
