R44B rechteckiges Gehäuse
Owin; Hannover
- Country
- Germany
- Manufacturer / Brand
- Owin; Hannover
- Year
- 1933 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 321764
Die untere Rückwand fehlt.
Bild ebay
- Number of Tubes
- 4
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); Anode bend detection
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries / 4 & ? Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: R44B [rechteckiges Gehäuse] - Owin; Hannover
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 400 x 465 x 195 mm / 15.7 x 18.3 x 7.7 inch
- Notes
-
Owin 2-Kreisempfänger R44B im Gehäuse entsprechend Modell L55W.
Siehe auch R44B im kathedralenförmigen Gehäuse.
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
