• Country
• United States of America (USA)

• Manufacturer / Brand
• Packard Bell Co.; Los Angeles (CA)

• Year
• 1953 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 361377

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 26

• Valves / Tubes
• 6BK7 or 6BQ7 6J6 6CB6 6CB6 6CB6 6CB6 6AL5 6AU6 6K6GT 6AU6 6AU6 6CB6 6AL5 12AX7 6V6GT 12AU7 6J5 6S4 6AL5 6SN7GT 6J5 6AV5GT or 6AU5GT 6AX4GT 1B3GT 5U4G 24BP4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2622 Ch= 2621-2 - Packard Bell Co.; Los Angeles

• Shape
• Tablemodel, with any shape - general.

• Notes

• Packard-Bell model 2622 is a 24” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 2621-2, VHF tuner 10531 and picture tube 24BP4.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 196, folder 10, dated 3-53)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
